Hoenle UV Micro Puck Multi Integrator
Hoenle UV Micro Puck Multi Integrator
SKU:512422
No se pudo cargar la disponibilidad de retiro
The UV Micro Puck Multi Integrator is a wireless UV dose measurement system designed for monitoring UV curing processes, including applications where UV intensity or dose needs to be measured in hard-to-reach areas.
Its compact wireless sensor units can be positioned directly at the desired measurement location. During the curing process, the sensor accumulates the received UV radiation. After measurement, the sensor is connected to the handheld integrator, which displays the accumulated UV dose in mJ/cm².
The system supports up to eight wireless sensor units and offers multiple spectral ranges, allowing the appropriate sensor to be selected based on the UV source and application.
Key Features
- Wireless UV dose measurement
- Compact sensors for measuring UV radiation in hard-to-reach areas
- Supports up to 8 sensor units
- Multiple spectral ranges available
- Measures accumulated UV dose in mJ/cm²
- Switchable measurement sensitivity
- Suitable for conventional UV and UV LED curing applications
- Compact and portable handheld unit
- Ideal for industrial UV curing and printing applications
Applications
The UV Micro Puck Multi Integrator is suitable for a variety of UV measurement and curing applications, including:
- UV curing systems
- UV LED curing
- Tube printing
- Bottle printing
- 3D object irradiation
- Industrial printing applications
- UV process monitoring
- UV dose verification
- Measurements in confined or difficult-to-access areas
Available Sensor Spectral Ranges
The system can be used with different sensor units depending on the required spectral range:
| Sensor | Spectral Range |
|---|---|
| Full UV | 230–410 nm |
| UV-C | 230–280 nm |
| UV-B | 280–315 nm |
| UV-A | 315–410 nm |
| UV-VIS | 395–445 nm |
| UV-LED | 265–495 nm |
The UV-LED sensor is designed for measurements of UV LED sources, particularly in the approximately 320–405 nm range.
Technical Specifications
| Specification | Value |
| Measurement Range | 10–5,000 mW/cm² |
| Display Range | 0–2,000 mJ/cm² |
| Extended Display Range | 0–20,000 mJ/cm², factor 10 |
| Display | LCD, 2 × 16 digits |
| Maximum Sensor Temperature | 230°F (110°C) for 10 seconds |
| Sensor Dimensions | 1.57 × 0.55 × 0.47 in (40 × 14 × 12 mm) |
| Sensor Weight | Approx. 1.06 oz (30 g) |
| Handheld Dimensions | 5.16 × 2.99 × 1.14 in (131 × 76 × 29 mm) |
| Handheld Weight | Approx. 6.7 oz (190 g) |
| Protection Class | IP20 |
| Sensor Connection | Wireless |
| Maximum Number of Sensors | Up to 8 |
| Measurement Sensitivity | Switchable 10× range |
System Configuration
The UV Micro Puck Multi Integrator consists of a handheld integrator and wireless sensor units. One handheld unit can be used with up to eight sensor units, allowing measurements across different locations or spectral ranges.
Sensor units are available separately and can be selected according to the specific UV source and application requirements.
Important
The UV Micro Puck Multi Integrator base unit does not include a sensor. Compatible sensor units are available separately.
For applications requiring a specific spectral range, select the appropriate sensor unit for the UV source being measured.
Why Use the UV Micro Puck Multi Integrator?
Accurate UV dose measurement is essential for monitoring and maintaining consistent UV curing processes. The wireless, compact design of the Micro Puck sensors makes it possible to measure UV exposure in locations where conventional measuring instruments may be difficult to position.
With support for multiple sensor types and up to eight sensor units, the UV Micro Puck Multi Integrator provides a flexible solution for UV curing process monitoring across a wide range of industrial applications.
CureUV is an authorized Hoenle distributor, supplying Hoenle UV measurement and process monitoring equipment for professional and industrial applications.
