Atlantic Ultraviolet Replacement 05-0839 UVC Light Bulb

No Pin Single Ended (Wire Lead) – 120 Watt Germicidal UVC Light Bulb

Our Atlantic Ultraviolet 05-0839 Generic Replacement UVC Light Bulb is a high-output, no-pin single-ended germicidal lamp featuring a B49 base with a 2-wire lead configuration (9" pigtail). This 120-watt UV lamp has a total length of 1453 mm (57.2") and is designed for use in professional water and air disinfection systems. The germicidal UV bulb is compatible with the following models and part numbers:

American Ultraviolet

• GCL-60
• PEK-60-120
• PEK-60-230
• PEK-60-277

The UV light bulb works effectively with germicidal OEM water treatment systems, UV purifiers, and sanitizers. The lamp is thoroughly tested and provides up to 10,000 hours of UV output. With a peak output at 253.7 nm, the lamp emits ultraviolet energy that photo-chemically reacts with the DNA of microorganisms, rendering them incapable of reproducing. Studies show that UV purification can destroy up to 99.9% of harmful microorganisms.

This method of UV disinfection does not alter the pH, taste, or chemistry of water and provides a chemical-free alternative to traditional disinfection methods such as chlorination. With UVC light technology, you can effectively eliminate pathogens such as bacteria, viruses, molds, and yeasts.

CureUV’s ultraviolet lamps are manufactured using high industry standards and meet or exceed OEM specifications. Each lamp undergoes strict quality control inspection to ensure consistent performance and reliability.

Technical Specifications:

• Total Length: 57.2 inches (1453 mm)
• Lamp Quartz Diameter: 22 mm
• Operating Current: Preheat
• Lamp Wattage: 120 Watts
• Output: High Output (HO)
• Peak UV Output: 253.7 nm
• Glass Type: Non-Ozone
• Base Style: B49 – No Pin, Single Ended, Wire Lead
• Wiring: Preheat, 2-wire (9" pigtail)
• Base Material: Ceramic
• Rated Life: Up to 10,000 hours

Common Applications:

• Aquaculture
• Beverage Processing
• Drinking Water Systems
• Food Processing
• HVAC & Air Treatment
• Industrial Water Treatment
• Surface Disinfection

Common Locations for Use:

• Factories
• Farms
• Hospitals
• Hotels
• Laboratories
• Industrial Facilities

*Warning: Ultraviolet UV-C light is harmful to your eyes and skin. Use proper safety gear.
