CureUV Double-Head Wood Polishing Machine

CureUV Double-Head Wood Polishing Machine

512311

CureUV’s Double-Head Wood Polishing Machine delivers precise, high-performance surface finishing for demanding wood production environments. Engineered to polish lacquered or oiled panels with consistency and speed, it integrates seamlessly into automated finishing lines to produce smooth, uniform, and high-gloss surfaces ready for final assembly or packaging. Built with a robust steel structure, premium motor components, and frequency-controlled operation, this system ensures reliable industrial performance, reduced manual labor, and consistent results across every production run. When surface quality, efficiency, and durability are critical, CureUV is your trusted finishing solution.



Aussi connu sous le nom de :

Afficher tous les détails

CureUV Double-Head Wood Polishing Machine

This industrial polishing machine is designed to achieve perfectly smooth and uniform finishes on wood panels after coating with lacquer or oil. It refines surfaces through precision polishing rolls, delivering flat, consistent, and high-gloss results ideal for professional production environments.

Production Capacity

  • Output capacity: Up to 500 meters/hour

  • Working speed: Up to 12 m/min

  • Optimized for continuous production lines and high-volume manufacturing

Key Performance Benefits

Superior Surface Quality

Delivers smooth, uniform finishes free from swirl marks or uneven areas. Ideal for high-end coated panels requiring a professional polish.

High Efficiency

Processes panels significantly faster than manual polishing, increasing production throughput while reducing labor costs.

Consistent Results

Ensures identical finishing quality across large production runs, maintaining uniform standards panel after panel.

Technical Specifications

Specification 24 in Working Width 39 in Working Width (calculated) 51 in Working Width
Working Width 24 in (600 mm) 39 in (990 mm) 51 in (1300 mm)
Steel Structure Thickness 0.63 in (16 mm) 0.63 in (16 mm) 0.63 in (16 mm)
Conveyor Belt Dimensions (L × W) 114.76 × 24.41 in (2915 × 620 mm) 114.76 × 39.76 in (2915 × 1010 mm) 114.76 × 51.97 in (2915 × 1320 mm)
Number of Motors 3 pcs 3 pcs 3 pcs
Motor / Converter Brand Liongoal / Schneider Liongoal / Schneider Liongoal / Schneider
Frequency Converter Controlled Standard Standard Standard
Total Power 12.07 HP (9.00 kW) 14.31 HP (10.67 kW) 16.09 HP (12.00 kW)
Overall Length 55.12 in (1400 mm) 55.12 in (1400 mm) 55.12 in (1400 mm)
Overall Width 35.43 in (900 mm) 50.79 in (1290 mm) 62.99 in (1600 mm)
Overall Height 55.12 in (1400 mm) 55.12 in (1400 mm) 55.12 in (1400 mm)



We can customize these systems to fit your needs exactly. Whether you need more power or a wider roller coater, we would love to help you with your system. Please contact us at sales@cureuv.com or between 8:00 a.m. and 4:30 p.m. EST at 1(800) 977-7292.
