10" String Wound Polypropylene Sediment Filter – 50 Micron

The 10" String Wound Polypropylene Sediment Filter (UP50R10P) is a high-performance depth filtration cartridge designed to reduce coarse sediment from water and compatible process fluids. Manufactured from commercial-grade polypropylene cord wound around a rigid polypropylene core, this filter provides effective particle retention while maintaining low pressure drop throughout its service life.

The UP50R10P utilizes true depth filtration, allowing particles such as sand, silt, rust, and scale to be captured throughout the entire filter matrix rather than just on the surface. This design results in a higher dirt-holding capacity and longer operational life. The polypropylene construction provides broad chemical compatibility and resistance to degradation, making the cartridge suitable for potable water systems as well as a wide range of industrial fluids.

Features & Benefits

• String Wound Polypropylene Construction: Durable, tightly wound fiber structure ensures consistent depth filtration.
• Nominal 50-Micron Rating: Effectively reduces sediment, dirt, sand, rust, and scale particles.
• True Depth Filtration: High dirt-holding capacity with minimal pressure loss over time.
• Wide Application Compatibility: Suitable for residential, commercial, and industrial filtration systems.
• High Temperature Resistance: Rated for continuous operation up to 200°F (93°C).
• Drop-In Cartridge Design: Fits standard 10" housings requiring a 2.5" diameter filter.
• Polypropylene Media & Core: Chemically resistant and safe for potable water use.

Typical Applications

• Well water sediment reduction
• Lake water sediment filtration
• Food and beverage processing
• Chemical processing
• Pharmaceutical manufacturing
• Electronics and precision manufacturing

Technical Specifications

• Model: UP50R10P
• Filter Length: 10"
• Filter Diameter: 2.5"
• Micron Rating (Nominal): 50 µm
• Filter Construction: String wound
• Filter Type: Sediment depth filter
• Media Material: Polypropylene fiber cord
• Core Material: Polypropylene
• End Configuration: Double Open End (DOE)
• Maximum Operating Temperature: 200°F (93°C)
