Opsytec UV Irradiation Chamber BS-02

Opsytec UV Irradiation Chamber BS-02

512180

The BS-02 irradiation chamber delivers precise and uniform UV exposure, supporting UV-C, UV-B, or UV-A lamps for maximum irradiance. Two independently controlled lamp groups allow flexible spectral operation.

With tool-free interchangeable lamps and a spacious 49 x 32 x 23 cm chamber, it ensures uniform irradiation while maintaining a controlled 25°C - 30°C temperature to prevent specimen damage.

For precision control, the BS-02 supports two advanced controllers:

  • UV-MAT: Compensates for lamp aging, contamination, and temperature fluctuations.
  • UV-MAT Touch: Features a high-resolution touchscreen, Cortex ARM processor, and Windows 10/11 compatibility for advanced control and documentation.
    Compact, adaptable, and reliable, the BS-02 is the perfect choice for controlled UV irradiation.

Technical specifications

Interior chamber 19.3 × 12.6 × 9.1 in (49 × 32 × 23 cm)
Dimensions 22.8 × 15.7 × 18.5 in (58 × 40 × 47 cm)
Power consumption 180 W
Lamp lifetime UVA up to 4,000 h
Lamp lifetime UVB up to 4,000 h
Lamp lifetime UVC up to 9,000 h
Number of lamps 8
Sample temperature 77 °F ± 9 °F (25 °C ± 5 °C)
Spectra ranges 2
Irradiance UVA 8 mW/cm²
Irradiance UVB 5 mW/cm²
Irradiance UVC 10 mW/cm²



Spectra of irradiation chamber BS-02

TDS
Spectral distribution

Opsytec UV Irradiation Chamber BS-02 Manual:

Enhanced Capabilities with UV-MAT Touch:

  • PC Compatibility: Works seamlessly with Windows 10/11 for multi-stage irradiations and comprehensive documentation.
  • Visual Insights: Offers clear numerical and graphical views of irradiations, oscillograms, and settings.
  • Secure Customization: Intuitive parameterization with password protection.
  • Precision Monitoring: Sensors include built-in analog-digital converters and temperature monitoring, with memory storage for calibration history and sensor identification.

The BS-02 irradiation chamber combines cutting-edge technology with user-friendly design to deliver exceptional performance for UV irradiation applications.
