UVPS 25" Arc Length UV Curing Replacement Lamp - 300WPI

UVPS 25" Arc Length UV Curing Replacement Lamp – 300 WPI – Mercury

This industrial UV curing lamp is designed as a compatible replacement for UVPS applications requiring a 25-inch arc length and 300 WPI output. The lamp features a mercury spectral chemistry, a 25 mm quartz tube diameter, and an overall length of approximately 30.35 inches.

Designed for reliable ultraviolet curing performance, this replacement lamp provides the high-intensity UV output required to polymerize and cure UV-sensitive inks, coatings, varnishes, and adhesives. It is suitable for industrial printing, signs and graphics, coating lines, and other UV curing equipment using a compatible 25-inch lamp configuration.

Specifications:

• Arc Length: 25 in
• Overall Length: Approximately 30.35 in
• Lamp Diameter: 25 mm
• Power Density: 300 WPI
• Spectral Chemistry: Mercury
• Application: Industrial UV curing
• Typical Uses: UV inks, coatings, varnishes, adhesives, signs, graphics, and printing applications

Replacement Lamp: Manufactured for dependable curing performance and designed to meet the operating requirements of compatible UVPS curing systems.

Cross-Reference / Replacement Part Numbers

• American Ultraviolet: A94251MCB
• American M&M / AWT: 576073
• American M&M / AWT: AE25-3009-C
• American M&M / AWT: 25-3009-C
• Western Quartz: 25-30009-C
• Western Quartz: 25-30009C
• Hanovia: 6825A444
• Hanovia: 6825A8C
• Alternate Lamp Reference: H25B13F1
• Alternate Lamp Reference: UVL 625
• Alternate Lamp Reference: 215100
• Alternate Lamp Reference: GA294251
• Alternate Lamp Reference: S6825A22C
• Alternate Lamp Reference: 6825A22C
• Alternate Lamp Reference: H25D3F3
• CureUV: 196328

Also searched as: 25" 300 WPI UV lamp, A94251MCB, 576073, AE25-3009-C, 25-3009-C, Western Quartz 25-30009-C, Hanovia 6825A444, 6825A8C, H25B13F1, UVL 625, 215100, GA294251, 6825A22C, H25D3F3.

Lamp Identification: 25" arc length, approximately 30.35" overall length, 25 mm lamp diameter, 300 WPI, mercury-spectrum medium-pressure UV curing lamp.

Cross-Reference Information: This lamp falls within the established 25" / 300 WPI mercury UV curing lamp family used in American M&M, AWT, American Ultraviolet, Hanovia, and related industrial curing systems. Published replacement catalogs associate this family with A94251MCB, 576073, AE25-3009-C, 25-3009-C, 25-30009-C, 6825A444, 6825A8C, H25B13F1, UVL 625, 215100, GA294251, S6825A22C, 6825A22C, and H25D3F3. Individual versions may use different overall lengths, end fittings, or lead configurations, so dimensional and electrical verification is required before substitution.

When cross-referencing this lamp with another manufacturer, verify the arc length, overall length, lamp diameter, electrical rating, spectral chemistry, and terminal/lead configuration before installation.
