Guaranteed 100% Compatible Replacement Ultraviolet (UV) Lamp - Mercury Wavelength - 9 Inch Arc Length - 12.5625 Inch Total Length (end to end)
The Vutek GS3200 45078276 UV Curing Lamp Bulb is a mercury-filled curing lamp bulb that is a guaranteed UV light bulb replacement for Vutek GS3200 UV Flatbed Printer. This replacement bulb is a compatible with the following part numbers:
- GS3200
- GS 3200
- 45078276
- 45088902
- 504927
- H09K1-3-F1
- H09K13F1
- UVL/3209
CureUV’s UV Curing Lamp Bulb is a 100% compatible replacement lamp that has an arc length of 9" and an overall length of 12.5625". The high performance replacement bulb has 340WPI and a tube diameter of 26mm. The guaranteed replacement UV bulb exceeds OEM standards of UV curing bulb performance and is one of the most effective and top quality UV emitters in the market.
The replacement lamp enables the drying of inks and coatings in signs and graphics. The curing lamp consists of quartz glass plate. This plate helps in protecting the lamp from debris and works as a filler between the lamp and the curing system. The quartz plate prevents dirt, grit and contaminants from building up.
The UV curing lamps are necessary for the drying system and are a better option to infra red drying as it resists smudges. UV Curing is an environmentally friendly process and also reduces the use of energy.
Technical Specifications:
- Fill: Mercury
- Quartz: Standard
- Arc Length: 9 Inches
- Overall Length: 12.5625 Inches
- Tube Diameter: 26mm
- Watts Per Inch: 340 WPI
Ultraviolet (UV) Spectral Output - Mercury Vapor Lamp (PDF)
EFI VUTEk GS3200 UV Lamp - Drawing (PDF)
*Hg - Lamp contains mercury - manage in accordance with your local disposal laws by visiting: www.lamprecycle.org
*All UV lamps listed are compatible brand UV products. We do not sell EFI/VUTEk brand UV lamps. All EFI/VUTEk brand names, trademarks and logos are property of EFI VUTEk.
*Warning: Ultraviolet light is harmful to your eyes and skin. Use proper safety gear.
Note: CureUV.com stocks generic products that are 100% compatible with the original equipment.
