UV Curing Lamp - MetalBox Part # MB426 UV Curing Lamp Bulb
UV Curing Lamp - MetalBox Part # MB426 UV Curing Lamp Bulb UV Curing Lamp - MetalBox Part # MB426 UV Curing Lamp Bulb UV Curing Lamp - MetalBox Part # MB426 UV Curing Lamp Bulb

MetalBox Part # MB426 UV Curing Lamp Bulb
Free Gift

SKU:

UV Bulb Price Match Guarantee
$198.00

Guaranteed 100% Compatible Replacement Ultraviolet (UV) Lamp - Mercury Wavelength - 6 Inch Arc Length - 9.8 Inch Total Length (end to end)

The Metalbox Part # MB426 UV Curing Lamp Bulb is a 100% compatible UV lamp bulb that exceeds OEM standards of UV curing bulb performance. The lamp bulb is 100% compatible to the UV curing lamp systems and works well with the following part numbers:

  • MB 426
  • AM3227X
  • 35206046
  • SLI106CDT182
  • PM426

The CureUV’s replacement bulbs work to cure dry coatings in signs and graphics. Made in the USA, the UV printer bulb provides a predictable lifespan and works to dry coatings and inks. With CureUV, you can be assured of UV lamps for printers in different arc length and spectral fills. Unlike curing using heat, the curing UV bulbs do not release volatile organic compounds in air that makes them an extremely eco-friendly option. The quartz plate in the curing lamp keeps the lamp away from debris and works as a filter between the curing system and the lamp. The usage of light instead of heat enables the ink to harden and dry instantly.

Technical Specifications:

  • Output Power: 500 WPI
  • Fill: Mercury
  • Quartz: Standard
  • Arc Length: 6 Inches
  • Overall Length: 9.80 Inches

UV Spectral Output of a Mercury UV Lamp(PDF)

UV Lamp - MetalBox UV System - MB426(PDF)

Note: CureUV.com stocks generic products that are 100% compatible with the original equipment.
