UV Process Supply (UVPS) Replacement Curing Lamp 5" Arc Length # UVPS 15021 - Iron Doped

Guaranteed 100% Compatible Replacement Ultraviolet (UV) Curing Lamp – 5" Arc Length (Iron Doped)

The UV Process Supply (UVPS) Replacement Curing Lamp # UVPS 15021 is a 5-inch arc length iron-doped UV curing bulb designed to meet or exceed OEM performance standards. This 100% compatible replacement lamp delivers enhanced curing performance, particularly for pigmented inks and coatings, by providing a broader spectral output compared to standard mercury lamps.

Manufactured using high-quality quartz and precision engineering, this iron-doped UV lamp produces consistent and uniform UV energy across the arc length, ensuring reliable curing results in demanding industrial environments. The iron doping enhances output in longer wavelengths, improving through-cure and adhesion in thicker or more challenging coatings.

Our replacement UV lamps are designed to provide OEM-equivalent quality at a cost-effective price point. With dependable performance and predictable lifespan, these lamps help maintain productivity and reduce downtime in UV curing systems.

Applications

• UV printing systems
• Industrial coating and finishing lines
• Ink and adhesive curing
• Graphics and signage production
• Packaging and labeling processes
• Applications requiring enhanced depth of cure (iron-doped spectrum)

Technical Specifications

• Arc Length: 5 inches
• Overall Length (TOL): 8.5 inches
• Lamp Diameter: 25.5 mm
• Leads: 3" wire leads with ring connectors
• Lamp Type: Iron-doped UV curing lamp
• Part Number: UVPS 15021

Cross-Reference / Replacement Part Numbers

• UV Process Supply (UVPS): 15021
• ANUM: 15021
• Patent / Patent-Licht: PAT/15021
• Theimer: 874920
• Theimer Lamp Reference: TQ 021014
• Theimer: 872920
• Theimer Lamp Reference: TQ 021015
• CureUV: 196329

Also searched as: UVPS 15021, UVPS15021, ANUM 15021, PAT/15021, Theimer 874920, Theimer TQ 021014, Theimer 872920, Theimer TQ 021015.

Lamp Identification: 5" arc length, 8.5" overall length, 25.5 mm lamp diameter, with 3" wire leads and ring connectors. Iron-doped spectral chemistry.

Cross-Reference Note: Legacy UV lamp catalogs associate ANUM 15021 with Theimer references 874920 / TQ 021014 and 872920 / TQ 021015. Because UV curing lamps may be offered in different spectral chemistries, verify that the replacement is the iron-doped version and confirm electrical characteristics, dimensions, and terminal configuration before installation.

When cross-referencing this lamp with another manufacturer, verify the arc length, overall length, lamp diameter, electrical rating, spectral chemistry, and terminal/lead configuration before installation.

Still not sure if this is what you need? We understand that figuring our replacements parts can be tricky so if you do have any questions, give us a call at 1(561)243-8442 or sales@cureuv.com.
